Q7V Dual Wireless Vocal Microphone System

$479.00

Complete dual channel / dual wireless microphone system for vocal. (Includes two Q7V AA powered hand held microphone and Quantum 7 99-channel dual receiver.

Clear

About Q7 Dual System

About

  • Dual Diversity receiver (Two mic / transmitters at the same time) with 100 Meter range.
  • Available in multiple frequency bands, 600-928mhz.
  • Dual receiver includes heavy duty metal chassis with rack ears.
  • 100 Channels region dependent with up to 30MHz bandwidth.
  • Compatible with all AMT microphones and Quantum 7 transmitters. (Q7 Clip-on, Q7B Beltpack, & Q7V Handheld.)
  • XLR & 1/4in Outputs
  • Optional rack tray available to mount two receivers  side by side for a total of 4 systems in one rack space.

Specifications

  • UHF 600-928MHz frequency range. Region Dependent.  (902-928, 863-865, 606-630, & 823-832)
  • PLL Synthesized circuit
  • Pre-set 200(100*2) selectable frequencies.
  • Digital Pliot tone-key control, high anti-interference capability
  • IR sync downloading the frequency from receiver
  • Optional function of Auto-scan the available clear frequency
  • LCD status of frequency, AF and RF signal etc
  • EIA standard 1U rack-mountable metal chassis
  • Up to 100 meters line-of-sight range
  • Ideal for professional stage, clubs, churches, and music.
  • Optional hand-held microphone, bodypack transmitter, and instrument transmitter available.

Comprehensive Performance

  • Carrier Frequency: UHF600-928MHz
  • Frequency Stabilization: <±30ppm
  • Dynamic Range: >95dB
  • Total Harmonic Distortion:<0.5%
  • Frequency Response: 40Hz-15KHz±3dB
  • Audio Output Level: Unbalance 400mV

Receiver

  • Power Supply: DC12-18V
  • Consume Power: 1 WATT
  • Signal/Noise Ratio: >105dB
  • Image &Spurious Rejection: >80dB
  • Border upon Channel Rejection: >80dB
  • Receiving Sensitivity: 5dBuV
  • De-Emphasis: 50uS
